- General
- Model
- Chamonix
- Weight
- 25.2 kg excluding battery
- Colour
- Ink blue gloss
- Sitting position
- Upright, active
- Frame shape
- High-Step, Low-Step
- E-bike technology
- Motor
- Shimano EP6
- Torque
- 85 Nm
- Motor position
- Mid-drive
- Maximum assisted speed
- 25 km/h / 15 mph
- Charger
- Shimano, 2 Ah
- Support levels
- 3
- Support modes
- Eco, Sport, High
- Walk assist
- Yes
- Display
- Shimano SC-EN610
- Display type
- LCD colour
- Display removable
- Yes
- Battery and range
- Battery options
- Shimano Intube 504 Wh or 630 Wh
- 630 Wh range
- Eco 180 km, Sport 115 km, High 85 km
- 504 Wh range
- Eco 150 km, Sport 95 km, High 70 km
- Battery brand
- Shimano
- Wheels and tyres
- Front wheel size
- 28-inch
- Rear wheel size
- 28-inch
- Front hub
- Shimano
- Rear hub
- Shimano Nexus 5
- Front tyre
- Schwalbe Big Apple
- Rear tyre
- Schwalbe Big Apple
- Brake and transmission
- Number of gears
- 5
- Gear type
- Hub
- Gear system
- Shimano Nexus 5
- Drivetrain
- Gates belt drive
- Front brake
- Hydraulic disc brake
- Rear brake
- Hydraulic disc brake
- Frame and fork
- Frame sizes
- High-Step and Low-Step options
- Fork suspension
- Mono Integrated
- Fork travel
- 40 mm
- Fork lockout
- No
- Handlebar and seat
- Handlebar
- Aluminium, slightly curved
- Adjustable stem
- Yes
- Grips
- Ergon GC10 ergonomic plastic handlebar grips
- Saddle
- BBB Diamond
- Seatpost suspension
- Yes
- Lighting
- Front light
- Trelock Veo 50, powered by main battery
- Rear light
- AXA Blueline, powered by main battery
- Equipment
- Lock
- Axa ring lock with option for plug-in cable; ART** classification
- Kickstand
- Ursus Mooi drop-down rear stand
- Rear carrier
- Aluminium MIK HD system carrier
- Carrier MIK profile
- Yes
- Front carrier
- No
- Warranty
- Frame warranty
- 10 years
- Fork warranty
- 5 years
- Paint warranty
- 5 years
- Battery warranty
- 2 years
- Motor warranty
- 2 years
- Display warranty
- 2 years
- Other parts warranty
- 2 years
Product specifications, battery range and pricing may change without prior notice. Non-contractual information.
